MODEL |
HD-AH240DT |
Image Sensor |
1/3" SONY 1.3Mega Exmor CMOS Sensor |
Effective Pixels |
1305(H) X 1049(V), 1.37M Pixels |
Total pixels |
1312(H) X 1069(V), 1.40M Pixels |
Scanning System |
Progressive Scan |
S/N Ratio |
More than 50dB |
Resolution |
1000TVL |
Video Output |
1.0Vp-p Composite. 75 Ohms |
Minimum Illumination |
0.1Lux |
LENS |
DC/MANUAL |
OSD |
Built-in |
BLC |
O |
HSBLC |
O |
D-WDR |
O |
White Balance |
ATW(1,700K ~ 11,000K) / AWC ? Set / Manual /AWB |
Shutter Speed |
AUTO /FLK/ 1/60(1/50)Sec ~ 1/50000Sec, x2, x4, x6, x8, x10, x15, x20,x25, x30 |
Sense-Up |
x2 ~ x30 |
Brightness |
0 ~ 100, Default : 45 |
Digital Noise Reduction |
2D, 3DNR |
De-Fog |
O (Position, Area Ajustable) |
Motion |
ON / OFF (4 Area) |
Digital Noise Reduction |
3DNR (OFF/LOW/MIDDLE/HIGH) |
Privacy |
ON / OFF (4 Area) |
brightness |
0 ~ 100, Default : 45 |
Mirror |
MIRROR,V-FLIP, ROTATE |
Privacy |
ON / OFF (4 Area) |
Freeze |
O |
Sharpness |
0~10(Level Adjustable) |
Language |
ENG/ARB/HEB/TUR/NED/POR/RUS/POL/SPA/ITA/FRA/GER/KOR/CHN1/CHA2/JPN |
Lens |
DC / MANUAL |
Power |
DC12V |
Power Consumption |
DC12V 180mA ±10%(MAX) |
Operating Temperature |
-10 ~ +50 Deg C. RH 95% Max. |
Storage Temperature |
-20 ~ +60 Deg C. RH 95% Max. |
Dimension |
|
Weight |
|
Storage Temp. |
-20 ~ +60 Deg C. RH 95% Max. |
Dimensions |
100mm(W) * 80mm(H) * 100mm(D) |
Weight |
600g |
